Durable All-Weather Fuel Dispenser Hose Assemblies for Gas Stations and Industrial Fueling

Whether at a busy gas station in North America, a highway service area in Europe, or an industrial fuel depot in Asia, fuel dispenser hoses are a critical component for safe and efficient fueling. The HAIBO Series of fuel hoses and hose assemblies is meticulously engineered to withstand extreme environments, handle diverse fuel types, and provide long-lasting durability with ease of operation.

Global Standards and Versatile Specifications

The HAIBO Series meets international standards, including HG/T3037 (China), UL330 (USA), EN1360 (Europe), AS2683 (Australia), and JISK6343 (Japan), making it suitable for use worldwide. People in different regions have different names for these products: in the United States, they are often called “gas pump hoses” or “fuel hose assemblies”; in the UK and Europe, “petrol dispenser hoses” or “fuel delivery hoses” are commonly used; in Japan, they are referred to as “燃料ホース” or “フューエルホースアセンブリ”.

The series offers multiple lengths (1.5 m to 10 m), color options (black, red, yellow, blue, green, grey, orange), and a variety of fixed and swivel end fittings. This versatility makes it ideal for retail fueling stations, commercial fleets, and industrial fuel systems. Customers can also customize hose diameter, fitting specifications, and pressure ratings according to their requirements.

Design Highlights and Safety Features

Inner Tube Material: Premium NBR (Nitrile Rubber) or CPE (Chlorinated Polyethylene) provides excellent resistance to gasoline, diesel, ethanol blends (E10–E85), and biodiesel blends (B20).

Reinforcement Layer: Single-layer high-tensile steel wire braid ensures flexibility, kink resistance, pressure endurance, and reliable conductivity. For high-pressure or extended-life applications, dual-layer textile braid and copper wire reinforcement can be customized.

Cover Protection: Durable CPE or CSM (Chlorosulfonated Polyethylene) cover offers outstanding resistance to ozone, weathering, abrasion, and light cracking, ensuring long-term reliability in outdoor environments.

Static Safety: Conductive inner tube and integrated copper wire allow continuous static discharge protection during fueling operations.

Global User Experiences

In California, USA, convenience store operators refer to it as a “flexible fuel hose”, appreciating its heat resistance and abrasion durability.

In Germany, industrial engineers call it “Zapfschlauch”, emphasizing its steel-wire strength and kink-resistant performance.

In Japan, refinery staff use “フューエルホース”, valuing static safety and chemical resistance.

HAIBO fuel dispenser hoses are more than just fueling tools—they represent a reliable, high-performance solution for safe and efficient fuel transfer. Whether you operate a retail station, manage a commercial fleet, or handle industrial fueling, this hose series delivers dependable, long-lasting service.

PREV：Versatile Brass and Aluminum Thread & Hose Connectors for Fuel Systems NEXT：No next product

Specification
Contact Us

HAIBO Series of fuel dispenser hoses are engineered to meet the toughest fueling environments and the most demanding standards worldwide. Designed for versatility, durability, and extreme weather performance, they are suitable for retail fueling stations, commercial fleets, and industrial applications. WITH DIFFERENT STANDARDS AS FOLLOWS: HG/T3037, UL330, EN1360, AS2683, JISK6343, ETC.

HG/T3037 Standard of Fuel Dispenser Hoses or Hose Assemblies (Black Color is our regular item in stock)

Series No. :HG/T3037-3/4 Name: Fuel Dispenser Hose Nominal size: 3/4” Inner Diameter: 19 mm Outer Diameter: 30 mm Max. working pressure: 1.6 MPa Test pressure:2.4 Mpa Max. Bursting pressure: 4.8 MPa Min. Bend radius: 100 mm Weight Per Meter: 0.697 kg Length:60 Meters/Roll Tube material: NBR Reinforcement: Single Wire Braid Cover: Chlorinated Polyethene Temperature: -40°C to +55°C	Series No. :HG/T3037-7/8 Name: Fuel Dispenser Hose Nominal size: 7/8” Inner Diameter: 22 mm Outer Diameter: 31.5 mm Max. working pressure: 1.6 MPa Test pressure:2.4 Mpa Max. Bursting pressure: 4.8 MPa Min. Bend radius: 130 mm Weight Per Meter: 0.770 kg Length:60 Meters/Roll Tube material: NBR Reinforcement: Single Wire Braid Cover: Chlorinated Polyethene Temperature: -40°C to +55°C	Series No. :HG/T3037-1 Name: Fuel Dispenser Hose Nominal size: 1” Inner Diameter: 25 mm Outer Diameter: 37 mm Max. working pressure: 1.6 MPa Test pressure:2.4 Mpa Max. Bursting pressure: 4.8 MPa Min. Bend radius: 150 mm Weight Per Meter: 0.982 kg Length:60 Meters/Roll Tube material: NBR Reinforcement: Single Wire Braid Cover: Chlorinated Polyethene Temperature: -40°C to +55°C

Series No. :HG/T3037-1.25 Name: Fuel Dispenser Hose Nominal size: 1.25” Inner Diameter: 32 mm Outer Diameter: 44 mm Max. working pressure: 1.6 MPa Test pressure:2.4 Mpa Max. Bursting pressure: 4.8 MPa Min. Bend radius: 175 mm Weight Per Meter: 1.145 kg Length:60 Meters/Roll Tube material: NBR Reinforcement: Single Wire Braid Cover: Chlorinated Polyethene Temperature: -40°C to +55°C	Series No. :HG/T3037-1.5 Name: Fuel Dispenser Hose Nominal size: 1.5” Inner Diameter: 38 mm Outer Diameter: 50 mm Max. working pressure: 1.6 MPa Test pressure:2.4 Mpa Max. Bursting pressure: 4.8 MPa Min. Bend radius: 225 mm Weight Per Meter: 1.339 kg Length:60 Meters/Roll Tube material: NBR Reinforcement: Single Wire Braid Cover: Chlorinated Polyethene Temperature: -40°C to +55°C

Ordering Specifications for Hose Assemblies:

Item No.	Size	Color	Length	Coupling Types
HG/T3037-3/4-B-1.5-FS	3/4”	Black	1.5 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-3/4-B-4-FS	3/4”	Black	4 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-3/4-B-5-FS	3/4”	Black	5 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-3/4-B-6-FS	3/4”	Black	6 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-3/4-B-8-FS	3/4”	Black	8 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-3/4-B-10-FS	3/4”	Black	10 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-3/4-R-1.5-FS	3/4”	Red	1.5 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-3/4-R-4-FS	3/4”	Red	4 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-3/4-R-5-FS	3/4”	Red	5 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-3/4-R-6-FS	3/4”	Red	6 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-3/4-R-8-FS	3/4”	Red	8 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-3/4-R-10-FS	3/4”	Red	10 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-1-B-1.5-FS	1”	Black	1.5 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-1-B-4-FS	1”	Black	4 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-1-B-5-FS	1”	Black	5 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-1-B-6-FS	1”	Black	6 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-1-B-8-FS	1”	Black	8 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-1-B-10-FS	1”	Black	10 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-1-R-1.5-FS	1”	Red	1.5 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-1-R-4-FS	1”	Red	4 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-1-R-5-FS	1”	Red	5 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-1-R-6-FS	1”	Red	6 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-1-R-8-FS	1”	Red	8 Meter	Fixed Coupling X Swivel Coupling
HG/T3037-1-R-10-FS	1”	Red	10 Meter	Fixed Coupling X Swivel Coupling

Note: The hose’s size, colour, length, and both end fittings — including fixed and swivel couplings —as well as their thread standards, can all be customised.

Key Features:

Tube: High-quality NBR (Nitrile Rubber) for excellent fuel resistance.Compatible with a wide range of fuels, including gasoline, diesel, ethanol blends (E10–E85), and biodiesel blends (B20).

Reinforcement: Single high-tensile steel wire braid for strength and flexibility.Designed with a hardwall structure, offering low volume expansion, enhanced durability, kink resistance, and reliable conductivity for safety.

Cover: Durable CPE (Chlorinated Polyethene) with superior resistance to ozone, weather, and abrasion.

Length: Available in bulk lengths or custom-coupled assemblies

Colour Options: Multiple colour options: Black, Red, Yellow, Blue, Green, Grey, Orange

More Images for reference:

Long Hose Assembly	Short Hose Assembly	Colourful Hose Assembly

UL330 Standard of Fuel Dispenser Hoses or Hose Assemblies (Black Color is our regular item in stock)

Series No. : UL330-3/4 Name: Fuel Dispenser Hose Nominal size: 3/4” Inner Diameter: 19 mm Outer Diameter: 28.5 mm Max. working pressure: 50 Psi Test pressure:250 Psi Max. Bursting pressure:1000 Psi Min. Bend radius: Weight Per Meter: 0.601 kg Length:60 Meters/Roll Tube: Chlorinated Polyethene Reinforcement: Single Wire Braid Cover: Chlorinated Polyethene Temperature: -40°C to +70°C	Series No. : UL330-7/8 Name: Fuel Dispenser Hose Nominal size: 7/8” Inner Diameter: 22 mm Outer Diameter: 31.5 mm Max. working pressure: 50 psi Test pressure:250 Psi Max. Bursting pressure: 1000 Psi Min. Bend radius: Weight Per Meter: 0.788 kg Length:60 Meters/Roll Tube: Chlorinated Polyethene Reinforcement: Single Wire Braid Cover: Chlorinated Polyethene Temperature: -40°C to +70°C	Series No. : UL330-1 Name: Fuel Dispenser Hose Nominal size: 1” Inner Diameter: 25 mm Outer Diameter: 35 mm Max. working pressure: 50 psi Test pressure:250 Psi Max. Bursting pressure: 1000 Psi Min. Bend radius: Weight Per Meter:0.796Kg Length:60 Meters/Roll Tube: Chlorinated Polyethene Reinforcement: Single Wire Braid Cover: Chlorinated Polyethene Temperature: -40°C to +70°C

Series No. : UL330-1.25 Name: Fuel Dispenser Hose Nominal size: 1.25” Inner Diameter: 32 mm Outer Diameter: 44 mm Max. working pressure: 50 psi Test pressure:250 Psi Max. Bursting pressure: 1000 Psi Min. Bend radius: Weight Per Meter: 1.171 kg Length:60 Meters/Roll Tube: Chlorinated Polyethene Reinforcement: Single Wire Braid Cover: Chlorinated Polyethene Temperature: -40°C to +70°C	Series No. : UL330-1.5 Name: Fuel Dispenser Hose Nominal size: 1.5” Inner Diameter: 38 mm Outer Diameter: 50 mm Max. working pressure: 50 psi Test pressure:250 Psi Max. Bursting pressure: 1000 Psi Min. Bend radius: Weight Per Meter: 1.372 kg Length:60 Meters/Roll Tube: Chlorinated Polyethene Reinforcement: Single Wire Braid Cover: Chlorinated Polyethene Temperature: -40°C to +70°C	Series No. : UL330-5/8 Name: Fuel Dispenser Hose Nominal size: 5/8” Inner Diameter: 16 mm Outer Diameter: 25.6 mm Max. working pressure: 50 psi Test pressure:250 Psi Max. Bursting pressure: 1000 Psi Min. Bend radius: Weight Per Meter: 0.516 kg Length:60 Meters/Roll Tube: Chlorinated Polyethene Reinforcement: Single Wire Braid Cover: Chlorinated Polyethene Temperature: -40°C to +70°C

Ordering Specifications for Hose Assemblies:

Item No.	Size	Color	Length	Coupling Types
UL330-3/4-B-1.5-FS	3/4”	Black	1.5 Meter	Fixed Coupling X Swivel Coupling
UL330-3/4-B-4-FS	3/4”	Black	4 Meter	Fixed Coupling X Swivel Coupling
UL330-3/4-B-5-FS	3/4”	Black	5 Meter	Fixed Coupling X Swivel Coupling
UL330-3/4-B-6-FS	3/4”	Black	6 Meter	Fixed Coupling X Swivel Coupling
UL330-3/4-B-8-FS	3/4”	Black	8 Meter	Fixed Coupling X Swivel Coupling
UL330-3/4-B-10-FS	3/4”	Black	10 Meter	Fixed Coupling X Swivel Coupling
UL330-3/4-R-1.5-FS	3/4”	Red	1.5 Meter	Fixed Coupling X Swivel Coupling
UL330-3/4-R-4-FS	3/4”	Red	4 Meter	Fixed Coupling X Swivel Coupling
UL330-3/4-R-5-FS	3/4”	Red	5 Meter	Fixed Coupling X Swivel Coupling
UL330-3/4-R-6-FS	3/4”	Red	6 Meter	Fixed Coupling X Swivel Coupling
UL330-3/4-R-8-FS	3/4”	Red	8 Meter	Fixed Coupling X Swivel Coupling
UL330-3/4-R-10-FS	3/4”	Red	10 Meter	Fixed Coupling X Swivel Coupling
UL330-1-B-1.5-FS	1”	Black	1.5 Meter	Fixed Coupling X Swivel Coupling
UL330-1-B-4-FS	1”	Black	4 Meter	Fixed Coupling X Swivel Coupling
UL330-1-B-5-FS	1”	Black	5 Meter	Fixed Coupling X Swivel Coupling
UL330-1-B-6-FS	1”	Black	6 Meter	Fixed Coupling X Swivel Coupling
UL330-1-B-8-FS	1”	Black	8 Meter	Fixed Coupling X Swivel Coupling
UL330-1-B-10-FS	1”	Black	10 Meter	Fixed Coupling X Swivel Coupling
UL330-1-R-1.5-FS	1”	Red	1.5 Meter	Fixed Coupling X Swivel Coupling
UL330-1-R-4-FS	1”	Red	4 Meter	Fixed Coupling X Swivel Coupling
UL330-1-R-5-FS	1”	Red	5 Meter	Fixed Coupling X Swivel Coupling
UL330-1-R-6-FS	1”	Red	6 Meter	Fixed Coupling X Swivel Coupling
UL330-1-R-8-FS	1”	Red	8 Meter	Fixed Coupling X Swivel Coupling
UL330-1-R-10-FS	1”	Red	10 Meter	Fixed Coupling X Swivel Coupling

Note: The hose’s size, colour, length, and both end fittings — including fixed and swivel couplings — as well as their thread standards, can all be customised.

Key Features:

Tube: CPE (Chlorinated Polyethene) for excellent fuel resistance.Compatible with a wide range of fuels, including gasoline, diesel, ethanol blends (E10–E85), and biodiesel blends (B20).

Cover: Durable CPE (Chlorinated Polyethene) with superior resistance to ozone, weather, and abrasion.

Length: Available in bulk lengths or custom-coupled assemblies

Colour Options: Multiple colour options: Black, Red, Yellow, Blue, Green, Grey, Orange

More Images for reference:

Long Hose Assembly	Short Hose Assembly	Colourful Hose Assembly

EN1360 Standard of Fuel Dispenser Hoses or Hose Assemblies (Black Color is our regular item in stock)

Series No. :EN1360-3/4 Name: Fuel Dispenser Hose Nominal size: 3/4” Inner Diameter: 19 mm Outer Diameter: 29 mm Max. working pressure: 232 Psi Test pressure:348 Psi Max. Bursting pressure:696 Psi Min. Bend radius: 100 mm Weight Per Meter: 0.478 kg Length:60 Meters/Roll Tube material: Conductive NBR Reinforcement: Single tensile textile Braid with a copper wire for connecting the two sides’ fittings. Cover: Chlorosulfonated Polyethylene(CSM) Temperature: -40°C to +55°C	Series No. :EN1360-7/8 Name: Fuel Dispenser Hose Nominal size: 7/8” Inner Diameter: 21 mm Outer Diameter: 31 mm Max. working pressure: 232 psi Test pressure:348 Psi Max. Bursting pressure: 696 Psi Min. Bend radius:130 mm Weight Per Meter: 0.488 kg Length:60 Meters/Roll Tube material: Conductive NBR Reinforcement: Single tensile textile Braid with a copper wire for connecting the two sides’ fittings. Cover: Chlorosulfonated Polyethylene(CSM) Temperature: -40°C to +55°C

Series No. :EN1360-5/8 Name: Fuel Dispenser Hose Nominal size: 5/8” Inner Diameter: 16 mm Outer Diameter: 26 mm Max. working pressure: 232 psi Test pressure:348 Psi Max. Bursting pressure: 696 Psi Min. Bend radius: 80 mm Weight Per Meter: 0.345 kg Length:60 Meters/Roll Tube material: Conductive NBR Reinforcement: Single tensile textile Braid with a copper wire for connecting the two sides’ fittings. Cover: Chlorosulfonated Polyethylene(CSM) Temperature: -40°C to +55°C	Series No. : EN1360-1 Name: Fuel Dispenser Hose Nominal size: 1” Inner Diameter: 25 mm Outer Diameter: 35 mm Max. working pressure: 232 psi Test pressure:348 Psi Max. Bursting pressure: 696 Psi Min. Bend radius: 150 mm Weight Per Meter:0.617Kg Length:60 Meters/Roll Tube material: Conductive NBR Reinforcement: Single tensile textile Braid with a copper wire for connecting the two sides’ fittings. Cover: Chlorosulfonated Polyethylene(CSM) Temperature: -40°C to +55°C

Ordering Specifications for Hose Assemblies:

Note: The hose’s size, colour, length, and both end fittings — including fixed and swivel couplings —as well as their thread standards, can all be customised. Note: For higher pressure, heavy-duty, or extended service life applications, we can customise hoses with two layers of textile braid reinforcement and copper wire upon request.

Key Features

Conductive NBR Inner Tube: Specially designed for safe fuel dispensing, offering excellent oil resistance and static conductivity.

Textile Braid Reinforcement: A single layer of high-tensile strength fibre ensures flexibility and reliable performance in daily use.

Copper Wire Integrated: Provides continuous electrical conductivity between both end fittings, ensuring static discharge protection.

Durable CSM Cover: Chlorosulfonated Polyethene (CSM) offers outstanding resistance to weathering, ozone, abrasion, and light cracking.

Length: Available in bulk lengths or custom-coupled assemblies

Colour Options: Multiple colour options: Black, Red, Yellow, Blue, Green, Grey, Orange

More Images for reference:

Long Hose Assembly	Short Hose Assembly	Colourful Hose Assembly
