Acrylic Sight-Glass Flanges for Real-Time Fuel Flow Observation
In fuel transportation and storage operations, visual verification of liquid flow is critical for safety, quality control, and accurate product identification. The HB806F-SG series of acrylic sight-glass flanges provides operators with a clear, real-time view of fuel presence and color, helping confirm that the correct product is being transferred.
These sight-glass flanges are installed between the pipe outlet flange and the inlet flange of API Bottom Loading Adaptors, creating a transparent observation window in the fuel transfer line. The bolt patterns and dimensions are drilled according to TTMA standards, and the flange thickness can be customized to meet the specific requirements of different users or operational setups.
This type of product is known by different names around the world, depending on regional terminology and industry practices. Common terms include acrylic sight-glass flange, fuel transfer observation flange, API loading adaptor sight window, transparent flow monitoring flange, tanker truck liquid inspection flange, and bottom loading adaptor visual indicator.
Despite the variations in naming, all of these products share the same core purpose: providing a clear visual confirmation of fuel flow, enabling easy inspection, and supporting safer and more efficient loading operations for tank trucks, fuel racks, and petroleum handling systems.
Key Advantages and Features
1. High-Visibility Material
Made of durable transparent acrylic, the flange allows operators to observe the liquid directly, ensuring proper product verification and color identification without relying solely on external instruments.
2. Compatibility and Customization
The HB806F-SG flanges are designed to match 4” API Bottom Loading Adaptors and adhere to TTMA bolt hole standards. Multiple thickness options are available, including 28 mm and 40 mm, and custom thicknesses can be produced to meet specific operational needs.
3. Wide Liquid Compatibility
These flanges are suitable for a variety of fuels, including non-ethanol gasoline (≤10% ethanol), diesel, kerosene, and other similar petroleum products, making them ideal for diverse fuel logistics operations worldwide.
4. Simple Installation and Maintenance
The flanges come with Buna-N gaskets, ensuring a leak-free connection and easy maintenance. Installation between the adaptor and pipeline requires no additional modifications, providing a convenient solution for both new installations and retrofit projects.
Typical Applications
The HB806F-SG acrylic sight-glass flanges are widely used in:
Road tanker fuel transfer systems
API bottom loading operations at fuel terminals
Service station gravity discharge pipelines
Fuel depot quality control lines
Petrochemical and fuel logistics inspection points
With their high visibility, durable construction, flexible thickness options, and global compatibility, the HB806F-SG series ensures safer, more efficient, and accurate fuel handling operations, providing operators worldwide with a reliable visual monitoring solution.
