HBREV-I Series Vapor Recovery Vent Valve – Efficient Tank Top Vapor Management

HBREV-I Series Vapor Recovery Vent Valve – Efficient Tank Top Vapor Management

The HBREV-I Vapor Recovery Vent Valve is a critical tank top component designed for fuel tank trucks. Installed on the manhole cover, the valve head sits inside the tank while the tail connects to the vapor recovery pipeline. It regulates vapor during bottom loading and unloading and ensures safe venting during transport. By opening the valve during loading and closing side vent valves, vapor can be recovered efficiently. When closed during transit, the valve seals the tank, preventing spills and enhancing operational safety.

Global Terminology Variations
This type of tank top vent valve is known differently worldwide, reflecting regional terminology while maintaining the same core function:
Germany: “Vapor-Rückgewinnungsventil für Tankdeckel”
France: “Vanne de récupération de vapeur pour trappe de réservoir”
Italy: “Valvola di recupero del vapore per coperchio serbatoio”
Spain: “Válvula de recuperación de vapor para tapa de registro”
Netherlands: “Vaporterugwinventiel voor tankluik”
UK: “Vapor Recovery Vent Valve for Tank Manhole”
In Asia and South America, it is often referred to as “油气回收通气阀” or “安全油气排放阀”.

Key Features
High-Quality Materials: Main body made of cast aluminum alloy, with seals in fluorine rubber or nitrile rubber for chemical resistance.
Rapid Vapor Flow: 4-inch diameter design ensures fast vapor recovery during high-speed loading/unloading.
Pneumatic Control: RC1/4" threaded air inlet with working pressure up to 0.8 MPa, minimum opening at 0.2 MPa.
Safety Design: Valve opens toward the cabin side, ensuring secure sealing during transport and preventing spills.
Temperature Range: Reliable operation from -20°C to +70°C.
TTMA Standard Flange: Compatible with international tank truck standards for easy installation.

Applications
The HBREV-I vapor recovery vent valve is widely used for:
Fuel tank trucks transporting gasoline and diesel
Chemical and industrial liquid tanker trucks
Any top-mounted tank access requiring safe vapor recovery and venting

Summary
The HBREV-I series provides reliable vapor management, combining pneumatic control, durable construction, and international standard compliance. Its design ensures efficient vapor recovery, safe venting, and protection against accidental spills during transport, making it a preferred choice for tank truck operators worldwide.
